Two Processing Methods for Etching Punched Nets

Its use is different and the processing methods are not the same.

  1. Chemical etching is to first screen the parts of the substrate that need to be protected by silk screen or screen printing, and then etch away the unwanted metal parts by chemical or electrochemical means. The environment, consciously oxidatively dissolves the surface of the stainless steel to give the stainless steel surface a special texture. Finally, the protective film is removed to obtain an etching process for the article.

  2. Electrolytic etching is carried out in a salt solution, the stainless steel to be etched is used as an anode, a special conductor mold is used as a cathode, and a low-voltage direct current is applied to make the voltage exceed the dissolution potential difference of the stainless steel, so that the stainless steel body metal is ionized. The form enters the electrolyte to achieve the purpose of etching. The process is more suitable for metal forming processing. The advantage is that the processed surface can maintain the original steel property, no deformation, air pollution is small, and the parts are easy to form. The disadvantage is that the equipment investment is large, and the metal interior is prone to "hydrogen embrittlement", The heat generated by electrolysis is not easy to bring out (uneven current distribution), the distance between the mold and the part to be etched (<0.5mm) is not easy to guarantee and the scorch phenomenon is easy to occur (the depth is not easy to control), and at the same time, due to its electrolytic edge effect and corrosion resistance Layers are easy to break down and are not suitable for etching of surface images.
  Metal etching is the direct use of strong acid or strong alkali solution to corrode unprotected parts of the workpiece, which is currently the most used method. The advantage is that the etching depth can be shallow and the etching speed is fast. The disadvantage is that the corrosive liquid has a great pollution to the environment. Moreover, the cost of etching the punching net is also large, and it is also troublesome to process.
